產品技術規格
| Product Attribute | Attribute Value |
|---|---|
| Class | Bluetooth Low Energy (BLE) |
| Manufacturer | Insight SiP |
| Product Category | Bluetooth Modules (802.15.1) |
| RoHS |
|
| Product | Bluetooth Modules |
| Core | ARM Cortex M4 |
| Data Rate | 2 Mb/s |
| Frequency | 2.4 GHz |
| Frequency Range | 2360 MHz to 2500 MHz |
| Mounting Style | SMD/SMT |
| Output Power | 8 dBm |
| Product Type | Bluetooth Modules |
| Memory Size | 256 kB, 1 MB |
| Length | 8 mm |
| Width | 8 mm |
| Height | 1 mm |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Dimensions | 8 mm x 8 mm x 1 mm |
| Supply Current Receiving | 5.4 mA |
| Supply Current Transmitting | 14.1 mA |
| Sensitivity | - 95 dBm |
| Operating Supply Voltage | 1.7 V to 5.5 V |
| Series | ISP1807 |
| Range | 100 m |
| Brand | Insight SiP |
| Factory Pack Quantity | 500 |
| Subcategory | Wireless & RF Modules |
